Directional Dual-Band Antenna for UAP-AC-M
UMA-D
$200.75
Sold Out
Directional Dual-Band Antenna for UAP-AC-M
The UniFi Antenna, model UMA-D, is an optional mesh antenna designed to work with the UniFi® AC Mesh AP, model UAP-AC-M. With dual-band support, the UMA-D expands range coverage and provides customized pattern shaping. It is available in single- and five-packs.
Features:
Dual-Band, Dual-Polarity Optimized for 802.11ac
High Efficiency Directional Radiation Pattern
Three-Axis Ball Joint Mount for Precise Aiming
(UMA-D)
Ubiquiti Directional Dual-Band Antenna for UAP-AC-M
Pack Includes:
- 1 x UMA-D Antenna
- 1 x Ball Joint Mount
- 1 x Lock Ring
- 4 x Screws
- 4 x Screw Anchors
- 1 x Hex Bolt
- 1 x Wall Mount Plate
- 1 x Metal Strap
- 2 x RF Cables
- Quick Start Guide
| UMA-D | |
|---|---|
| Dimensions | 201.3*128*32.5 mm |
| Weight | 400g without mount 480g with mount |
| Enclosure Characteristics | Outdoor UV Stabilized Plastic |
| RF Connections | (2) RP-SMA |
| Supported Frequency Range | 2.4-2.5GHz, 5.1-5.9GHz |
| 2.4GHz Band | |
| Gain | 10dBi |
| HPOL Beamwidth | 90 |
| VPOL Beamwidth | 90 |
| Elevation Beamwidth | 90 |
| Maximum VSWR | 2:1 |
| Polarization | Dual-Linear |
| Cross-Pol Isolation | 25dB |
| 5GHz Band | |
| Gain | 15dBi |
| HPOL Beamwidth | 45 |
| VPOL Beamwidth | 45 |
| Elevation Beamwidth | 45 |
| Maximum VSWR | 2:1 |
| Polarization | Dual-linear |
| Cross-Pol Isolation | 30dB |
SHIPPING SPECIFICATIONS
| SKU | UMA-D |
| Model # | UMA-D |
| Barcode # | 817882022736 |
| Brand | Ubiquiti |
| Shipping Weight | 0.5200kg |
| Shipping Width | 0.130m |
| Shipping Height | 0.035m |
| Shipping Length | 0.210m |
| Shipping Cubic | 0.000956000m3 |
| Unit Of Measure | ea |
Directional Dual-Band Antenna for UAP-AC-M - Documents
UMA-D DatasheetBe The First To Review This Product!
