ToughCable PRO Cat5e Outdoor Carrier By The Meter (BTM)

TC-PRO-BTM

$1.99
In Stock

Want Multiple Cables? Enter the number of meters you require and add to cart i.e. 15 = 1 x 15m cable. Repeat the process for multiple cables.

Outdoor Shielded Ethernet Cable By The Meter (BTM). Minimum 10M Length.



NOTE: Minimum 10M lengths when purchasing this item. For shorter length cables select the TC-PRO-PT here



Protect your networks from the most brutal environments with Ubiquiti’s industrial-grade shielded Ethernet cable, TOUGHCable™. A Category 5e, outdoor, carrier-class shielded cable with an integrated ESD drain wire. TOUGHCable PRO By The Meter (BTM) is cut to length, ideal for the smaller applications where a full 304m box is not required. TOUGH Cable Connectors are also available in box of 100 or 10 Packs for smaller applications.

Increased Performance

Dramatically improve your Ethernet link states, speeds, and overall performance with Ubiquiti TOUGHCables.

Extreme Weatherproof

TOUGHCables have been built to perform even in the harshest weather and environments.

ESD Damage Protection

Protect your networks from devastating electrostatic discharge (ESD) attacks.

Extended Cable Support

TOUGHCables have been developed to increase power handling performance for extended cable run lengths.

Additional Details

  • 24 AWG copper conductor pairs
  • 26 AWG integrated ESD drain wire to prevent ESD attacks and damage
  • PE outdoor-rated, weatherproof jacket
  • Multi-layered shielding
  • Available in lengths of 1000 ft (304.8 m)







(TC-PRO-BTM)

ToughCable Pro

1 x TOUGHCable PRO 3 ft (1m)

ToughCable Pro - Specifications

TOUGHCable PRO
Cable CAT5e, Shielded
Ethernet Support Up to 1 Gbps
Conductor Wire Gauge 24 AWG
Conductor Solid Bare Copper
Conductor Diameter 0.500 ± 0.005 mm
Insulation Type Solid PE
Insulation Thickness Avg. 0.26 mm, Min. 0.25 mm
Insulation Diameter 1.04 ± 0.03 mm
Separation (Polyester Wrapping) Thick: 0.025 mm, Extent: 20 mm
Anti-Crosstalk Divider None
Cable Shield (Aluminum Foil) Thick: 0.060 mm, Extent: 18 mm
ESD Drain Wire 0.4 CCS
Rip Cord Yes
Jacket Material PE
Jacket Thickness Avg. 0.50 mm, Min. 0.46 mm
Jacket Outer Diameter 6.0 ± 0.30 mm
Jacket Color Black
Reference Standard ISO/IEC 11801, TIA/EIA568B.2

Shipping Specifications

SKU TC-PRO-BTM
Model # TC-PRO
Brand Ubiquiti
Shipping Weight 0.1000kg
Shipping Width 0.010m
Shipping Height 0.020m
Shipping Length 0.100m
Shipping Cubic 0.000020000m3
Unit Of Measure m
