U Fiber Loco

UF-LOCO

$101.75

In Stock

ALTERNATE PRODUCT:

UF-WIFI-
U Fiber GPON with WiFi
In Stock: YES

Gigabit Passive Optical Network CPE

Sporting a sleek industrial design, the U Fiber loco is a robust, high‑performance GPON CPE that features extremely low power consumption and two power options.

Up to 128 UFiber loco devices can be connected to a single GPON port. Supporting GPON links of up to 20 km, the UFiber loco integrates with the UFiber OLT.

Gigabit Passive Optical Network CPE

Features

WAN: (1) GPON Port
LAN: (1) Gigabit Ethernet Port
GPON Speeds: 2.488 Gbps Downstream (RX), 1.244 Gbps Upstream (TX)
Wavelengths: 1490 nm Downstream (RX), 1310 nm Upstream (TX)
Max. Power Consumption: 3.5W
Power Method: 24V Passive PoE or Micro-USB Power Adapter*
Mounting: Wall-Mountable (Indoor)

* Included only in the single-pack of the UF-LOCO

List of Supported 3rd Party OLT's - Click Here

(UF-LOCO)

U Fiber Nano G

Pack Includes:

1 x Ubiquiti Fiber Loco
1 x Wall Mount Bracket
4 x Screws
4 x Screw Anchors
1 x Micro-USB Power Adapter* (5V, 1A)
Quick Start Guide

*POE Adapter Sold Separately

U Fiber Loco - Specifications

UF-LOCO	(1) GPON Port
Dimensions	76.5 x 76.5 x 26.4 mm (3.01 x 3.01 x 1.04")
Weight	77 g (2.72 oz)
Networking Interface Speeds	(1) GPON WAN, ITU G.984, 2.488 Gbps Downstream, 1.244 Gbps Upstream (1) GbE LAN, 10/100/1000 Mbps
Management Interface	In-Band Ethernet/PON
Normal Optical Power Range	TX (Class B+): 1.5 dBm to 5 dBm RX: -28 dBm to -8 dBm
Power Method	Micro-USB: 5V, 1A 24V Passive PoE (Pins +4, 5; -7, 8)
Power Supply	Micro-USB Power Adapter*: 5V, 1A
Max. Power Consumption	3.5W
Supported Voltage Range	4.7 to 5.3V
Processor Specs	MIPS32, 240 MHz
Memory Information	128 MB DDR3
Buttons	(1) Reset
Operating Temperature	-10 to 45° C (14 to 113° F)
Operating Humidity	10 to 90% Noncondensing
Certifications	CE, FCC, IC

* Included only in the single-pack of the UF-LOCO

Shipping Specifications

SKU	UF-LOCO
Model #	UF-LOCO
Barcode #	817882023559
Brand	Ubiquiti
Shipping Weight	0.2000kg
Shipping Width	0.080m
Shipping Height	0.030m
Shipping Length	0.080m
Shipping Cubic	0.000192000m3
Unit Of Measure	ea
