UniFi 24-Port Managed Gigabit Switch (No POE)

US-24

$375.38
Sold Out

Managed Gigabit Switches with SFP



Build and expand your network with Ubiquiti Networks® UniFi® Switch, part of the UniFi line of products. Available with 24 or 48 RJ45 Gigabit ports, the UniFi Switch is a fully managed Gigabit switch, delivering robust performance and intelligent switching for your growing networks.

Switching Performance
The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. For its total, non‑blocking throughput, the 24‑port model supports up to 26 Gbps, while the 48-port model supports up to 70 Gbps.

Fiber Connectivity
Each model includes two SFP ports for uplinks of up to 1 Gbps. The 48‑port model adds two SFP+ ports for high-capacity uplinks of up to 10 Gbps, so you can directly connect to a high‑performance storage server or deploy a long‑distance uplink to another switch.

(US-24)

UniFi Switch 24 Port No PoE

Package Includes

  • 1 x UniFi Switch 24
  • 2 x Mounting Brackets
  • 8 x Bracket Screws
  • 4 x Mounting Screws (#10-32 x 5/8")
  • 4 x Cage Nuts (#10-32 x 5/8")
  • 4 x Rubber Feet
  • 1 x Power Cord
  • Quick Start Guide

UniFi Switch 24 Port No PoE - Specifications

UNIFI SWITCH 24 (No PoE)
Dimensions 443 x 43 x 221 mm (17.44 x 1.69 x 8.70")
Weight 2.51 kg (5.53 lb), 2.60 kg (5.70 lb) with rack-mount bracket
Networking Interface (24) 10/100/1000 Mbps RJ45 Ethernet Ports, (2) 1 Gbps SFP Ethernet Ports
Management Interface (1) RJ45 Serial Port Out‑of‑Band (Reserved for Future Use), Ethernet In‑Band
Total Non-Blocking Throughput 26 Gbps
Switching Capacity 52 Gbps
Forwarding Rate 38.69 Mpps
Power Method 100‑240VAC/50‑60 Hz, Universal Input
Power Supply AC/DC, Internal, 25W DC
Max. Power Consumption 25W
Sound Level 34 dBa
Mounting Rack Mount, 1U High
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 5 to 95% Noncondensing
Certifications CE, FCC, IC

Shipping Specifications

SKU US-24
Model # US-24
Barcode # 8.18E+11
Brand Ubiquiti
Shipping Weight 2.7400kg
Shipping Width 0.265m
Shipping Height 0.075m
Shipping Length 0.547m
Shipping Cubic 0.010872000m3
Unit Of Measure ea

UniFi Switch 24 Port No PoE - Documents
