Access Point U6 In-Wall
U6-IW
Access Point U6 In-Wall
Wall-mounted WiFi 6 access point with a built-in PoE switch. The In Wall Access Point has 1 GbE PoE In and 1 PoE out Port with a total of 4 GbE ports offering complete flexability in every room.
Features:
- WiFi 6 support (2.4/5 GHz bands)
- 5.3 Gbps aggregate throughput rate
- (1) GbE RJ45 port (PoE In)
- (4) GbE RJ45 ports, including one that supports PoE output*
*PoE+ input required.(Switch or PoE Adapter)
(U6-IW)
Access Point U6 In-Wall
Pack Includes:
- 1 x Access Point U6 In-Wall
- 4 x Wall Screws
- 1 x Hex Key
- 1 x Wall Plate
- Quick Start Guide
*PoE NOT Included (Sold Separately)
Access Point U6 In-Wall - Specifications
| Mechanical | |||||
|---|---|---|---|---|---|
| Dimensions |
139.66 x 96 x 31.19 mm (5.5 x 3.78 x 1.28") |
||||
| Weight |
460 g (1.01 lb) |
||||
| Enclosure materials |
Plastic, aluminum |
||||
| Mount material |
Aluminum |
||||
| Hardware | |||||
| Management interfaces |
Ethernet Bluetooth |
||||
| Networking interfaces |
(1) Data-in: 1GbE RJ45 port (4) Data-out: 1GbE RJ45 ports |
||||
| PoE interfaces |
(1) PoE in (PoE output not used) |
||||
| Button |
Factory reset |
||||
| LED |
White/blue |
||||
| Power method |
PoE |
||||
| Power supply |
UniFi PoE switch |
||||
| Max. power consumption |
Excluding PoE output: 13.5W |
||||
| Max PoE wattage per port by PSE |
15.4W* |
||||
| Voltage range PoE mode |
44—57V DC |
||||
| Max. TX power |
|
||||
| MIMO |
|
||||
| Throughput rate |
|
||||
| Antenna gain |
|
||||
| Operating temperature |
-30 to 60° C (-22 to 140° F) |
||||
| Operating humidity |
5 to 95% noncondensing |
||||
| Certifications |
CE, FCC, IC |
||||
| Software | |||||
| WiFi standards |
802.11a/b/g |
||||
| Wireless security |
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
||||
| BSSID |
8 per radio |
||||
| VLAN |
802.1Q |
||||
| Advanced QoS |
Per-user rate limiting |
||||
| Guest traffic isolation |
Supported |
||||
| Concurrent clients |
300+ |
||||
| Zero-wait DFS |
Yes |
||||
| SKU | U6-IW |
| Model # | U6-IW |
| Barcode # | 810010077493 |
| Brand | Ubiquiti |
| Shipping Weight | 0.5000kg |
| Shipping Width | 0.110m |
| Shipping Height | 0.045m |
| Shipping Length | 0.150m |
| Shipping Cubic | 0.000742000m3 |
| Unit Of Measure | ea |
Access Point U6 In-Wall - Documents
Installation Guide Access Point U6 In-Wall Be The First To Review This Product!
